- Controls and displays
- During centrifugation the actual values of the parameters are indicated
- Entry of the running parameters via foil keypad
- Speed display in RPM or RCF
- RPM input from 200 to 10.000 in steps of 10, starting from 10.000 to the maximum speed in steps of 100
- RCF input from 200 to 10.000 in steps of 1, starting from 10.000 to the maximum speed in steps of 10
- Time t/min: 1 – 99 min. in steps of 1min., Time t/sec: 1-59 sec. in steps of 1 sec., Continuous operation
- Brake stage, selectable between fast and slow
- Pulse key: For short centrifugation operations
- Open lid key
- safety
- Lid locking and holding device
- Emergency lid lock release
- Motor overheating protection A Imbalance switch-off
- Deep metal rotor chamber (die-cast-zinc) to securely accomodate the rotor
The M-24 A conforms to safety regulations such as IEC 61010 or the CE
mark and all relevant EC standards and DIN norms and has been manufactured
under ISO 9001:2008
| Technical details | |
| Max. RPM (speed) / RCF: | 14,000 rpm / 18,845 RCF |
| Noise level: | =59 dB(A) |
| Emission / Immunity: | EN / IEC 61326-1 class B / FCC class B |
| Dimensions in mm: | 228 (H) x 262 (W) x 352 (D) |
| Net weight: | approx. 11 kg |
| Code | Description |
| BOE 01203-13 | BOECO centrifuge MC-24, 200-240 V, 50-60 Hz, without rotor |
| BOE 01203-12 | BOECO centrifuge MC-24, 100-127 V, 50-60 Hz, without rotor |
