Functions:
- drying modes
- samples drying
- water vapor permeability
- halogen
- humidity analysis
- dry mass determination
- elevated temperature level
- GLP/GMP procedures
| Specification | BMA H50 | BMA I50 |
| Heating Module | Halogen emitter | Infrared emitter |
| Range of Drying temp | 250°C | 160°C |
| Max. capacity | 50 g | 50 g |
| Readability | 0,001 g | 0,001 g |
| Tare range | – 50 g | – 50 g |
| Max mass sampling | 50 g | 50 g |
| Accuracy of moisture reading | 0,001 % | 0,001 % |
| Repeatability | ±0,05 % (sample < 2 g) | ±0,05 % (sample < 2 g) |
| ±0,06 % (sample 2-10 g) | ±0,06 % (sample 2-10 g) | |
| ±0,01 % (sample >10 g) | ±0,01 % (sample >10 g) | |
| Max. height of tested sample | h = 20 mm | h = 20 mm |
| Pan size | ø 90 mm, h = 8 mm | ø 90 mm, h = 8 mm |
| Drying modes | 4 drying modes (standard, quick, step, mild) | 4 drying modes (standard, quick, step, mild) |
| Auto switch off options | 4 options (manual, automatic, time defined, user-defined) | 4 options (manual, automatic, time defined, user-defined) |
| Aditional functions | sample identification | sample identification |
| Power of heating device | 400 W | 400 W |
| Interface | 2xRS232, 2xUSB (A+B), WIFI (optional) | 2xRS232, 2xUSB (A+B), WIFI (optional) |
| Display | LCD with backlight | LCD with backlight |
| Working temperature | +10°C – +40°C | +10°C – +40°C |
| Power Supply | 110-240 V AC, 50/60 Hz | 110-240 V AC, 50/60 Hz |
| Netweight / Grossweight | 4,9 kgs / 6,4 Kg | 4,9 kgs / 6,4 Kg |
| Size / Packing size | 333x206x190 / 470x380x336 mm | 333x206x190 / 470x380x336 mm |
Accessories
Accessories for BMA/BMX Moisture Analyzers
(1)
| Code | Description |
| BOE PAN90 | Auminium sample pans, round, Ø = 90 mm (box of 50) |
| BOE 440017 | Glass fiber filters MG 161, 90 cm Ø, with binder, anorganic, 75 g/m2(box of 50) |
| BOE F1-50 | Calibration weight, 50 g, F1, cylindrical shape. Nickel-plated and polished brass, packed in a lined plastic container, with DAkkS certificate |
